Multi Blade Slicing Machine
MB-1852
MB-1852
■Maximum Size of Workpiece : W220×D200×H180mm
■Maximum Weight of Workpiece : Approx. 20kg
■Machine Size : W1910×D464×H1000mm
Our newly designed abrasive coating multi blade slicing machine lightens the loads on a workpiece and the blades.
Uses : Cutting of magnetic materials such as ceramics, silicone, quartz, ferrite, and SmCo Magnets, and cutting of crystals at certain angles, free abrasive grain cutting.
Specifications
Power |
Frame Sliding System | AC200V three-phase 4P1.5kw |
| Circular Compensation (Stepping) | -- | |
| Abrasive Grain Pump | AC200V three-phase 2P100W | |
| Forced Oil lubricating Pump | AC200V three-phase 4P10W | |
| Ellipsoidal Rotation System for Abrasive Grain Outlet | AC200V three-phase 4P15W | |
| Lifting System for Abrasive Grain Outlet | AC200V single-phase 25W (with a brake) | |
| Cooling Fan | AC200V single-phase 14W | |
| Cooling Fan for Abrasive Grains | AC200V single-phase 60W (optional) | |
Moving Range |
Number of Sliding Frame Reciprocations | 0～100/min. (without steps) |
| Stroke of Sliding Frame | 212～320/3m/P (20 steps) | |
| Maximum Stroke of Vertical Movement | 190mm | |
| Maximum Circular Compensation | -- | |
| Up-and-Down Stroke of Abrasive Grain Outlet | 190mm/step, 2～8mm (select) | |
Blades |
Blade Size (length×width) | 520×12mm (maximum) |
| Effective Length | 450mm | |
Workpiece |
Maximum Size (W×D×H) | 220×200×180mm |
| Maximum Weight | Approx. 20kg | |
Tank Capacity |
Abrasive Grain Tank | 18 liters |
| Oil Tank | 2 liters | |
Machine Size and Weight |
Size (W×D×H) | 1910×464×1000mm |
| Weight | Approx.200kg |
The specifications and appearance of this machine might be changed for further improvement without any notice.
Note) The machine size does not include the protrusion parts.
MB-2563
MB-2563
■Maximum Size of Workpiece : W250×D320×H250mm
■Maximum Weight of Workpiece : Approx. 35kg
■Machine Size : W2220×D600×H1400mm
Our newly designed abrasive coating multi blade slicing machine lightens the loads on a workpiece and the blades.
Uses : Cutting of magnetic materials such as ceramics, silicone, quartz, ferrite, and SmCo Magnets,and cutting of crystals at certain angles, free abrasive grain cutting.
Specifications
Power |
Frame Sliding System | AC200V three-phase 4P2.2kw |
| Circular Compensation (Stepping) | -- | |
| Abrasive Grain Pump | AC200V three-phase 2P100W | |
| Forced Oil lubricating Pump | AC200V three-phase 4P10W | |
| Ellipsoidal Rotation System for Abrasive Grain Outlet | AC200V three-phase 4P15W | |
| Lifting System for Abrasive Grain Outlet | AC200V single-phase 25W (with a brake) | |
| Cooling Fan | AC200V single-phase 14W | |
| Cooling Fan for Abrasive Grains | AC200V single-phase 60W (optional) | |
Moving Range |
Number of Sliding Frame Reciprocations | 0～85/min. (without steps) |
| Stroke of Sliding Frame | 218～320/3m/P (18 steps) | |
| Maximum Stroke of Vertical Movement | 250mm |
|
| Maximum Circular Compensation | -- | |
| Up-and-Down Stroke of Abrasive Grain Outlet | 280mm/step, 2～8mm (select) | |
Blades |
Blade Size (length×width) | 630×15mm (maximum) |
| Effective Length | 550mm | |
Workpiece |
Maximum Size (W×D×H) | 250×320×250mm |
| Maximum Weight | Approx. 35kg | |
Tank Capacity |
Abrasive Grain Tank | 18 liters |
| Oil Tank | 2 liters | |
Machine Size and Weight |
Size (W×D×H) | 2220×600×1400mm |
| Weight | Approx.1600kg |
The specifications and appearance of this machine might be changed for further improvement without any notice.
Note) The machine size does not include the protrusion parts.
MB-3090A
MB-3090A
■Maximum Size of Workpiece : W320×D300×H300mm
■Maximum Weight of Workpiece : Approx. 75kg
■Machine Size : W2900×D730×H2030mm
We designed this machine to lighten the loads on a workpiece and the blades by using the mechanism of balance scales and the microcomputer-controlling circular compensation system to resolve the disadvantage of the leverage system.
Uses : Cutting of magnetic materials such as ceramics, silicone, quartz, ferrite, and SmCo Magnets, and cutting of crystals at certain angles, free abrasive grain cutting.
Specifications
Power |
Frame Sliding System | AC200V three-phase 4P3.7KW |
| Circular Compensation (Stepping) | AC200V (five-phase) | |
| Abrasive Grain Pump | AC200V three-phase 2P180W | |
| Forced Oil lubricating Pump | AC200V three-phase 4P10W | |
| Ellipsoidal Rotation System for Abrasive Grain Outlet | AC200V three-phase 2P15W |
|
| Lifting System for Abrasive Grain Outlet | AC200V single-phase 40W (with a brake) | |
| Cooling Fan | AC200V single-phase 14W | |
| Cooling Fan for Abrasive Grains | AC200V single-phase 60W (optional) | |
Moving Range |
Number of Sliding Frame Reciprocations | 0～60/min. (without steps) |
| Stroke of Sliding Frame | 276～500mm(40 steps) | |
| Maximum Stroke of Vertical Movement | 350mm (26.5º) |
|
| Maximum Circular Compensation | 84.8mm |
|
| Up-and-Down Stroke of Abrasive Grain Outlet | 450mm/step, 2～8mm (select) | |
Blades |
Blade Size (length×width) | 900×18mm (maximum) |
| Effective Length | 819mm | |
Workpiece |
Maximum Size (W×D×H) | 320×300×300（340）mm |
| Maximum Weight | Approx. 75kg | |
Tank Capacity |
Abrasive Grain Tank | 27 liters |
| Oil Tank | 2 liters | |
Machine Size and Weight |
Size (W×D×H) | 2900×730×2030mm |
| Weight | Approx.2000kg |
The specifications and appearance of this machine might be changed for further improvement without any notice.
Note) The machine size does not include the protrusion parts.
MB-4090A
MB-4090A
■Maximum Size of Workpiece : W400×D420×H400mm
■Maximum Weight of Workpiece : Approx. 160kg
■Machine Size : W3300×D1090×H2060mm
We designed this machine to lighten the loads on a workpiece and the blades by using the mechanism of balance scales and the microcomputer-controlling circular compensation system to resolve the disadvantage of the leverage system.
Uses : Cutting of magnetic materials such as ceramics, silicone, quartz, ferrite, and SmCo Magnets, and cutting of crystals at certain angles, free abrasive grain cutting.
Specifications
Power |
Frame Sliding System | AC200V three-phase 4P3.7kw |
| Circular Compensation (Stepping) | AC200V (five-phase) | |
| Abrasive Grain Pump | AC200V three-phase 2P180W | |
| Forced Oil lubricating Pump | AC200V three-phase 4P15W | |
| Ellipsoidal Rotation System for Abrasive Grain Outlet | AC200V three-phase 4P25W | |
| Lifting System for Abrasive Grain Outlet | AC200V single-phase 25W (with a brake) | |
| Cooling Fan | AC200V single-phase 14W | |
| Cooling Fan for Abrasive Grains | AC200V single-phase 60W (optional) | |
Moving Range |
Number of Sliding Frame Reciprocations | 0～60/min. (without steps) |
| Stroke of Sliding Frame | 310～400mm (15 steps) | |
| Maximum Stroke of Vertical Movement | 500mm (30.5º) |
|
| Maximum Circular Compensation | 134mm |
|
| Up-and-Down Stroke of Abrasive Grain Outlet | 450mm/step, 2～8mm (select) | |
Blades |
Blade Size (length×width) | 900×18mm (maximum) |
| Effective Length | 819mm |
|
Workpiece |
Maximum Size (W×D×H) | 400×420×400mm |
| Maximum Weight | Approx. 160kg | |
Tank Capacity |
Abrasive Grain Tank | 50 liters |
| Oil Tank | 2 liters | |
Machine Size and Weight |
Size (W×D×H) | 3300×1090×2060mm |
| Weight | Approx. 2500kg |
The specifications and appearance of this machine might be changed for further improvement without any notice.
Note) The machine size does not include the protrusion parts.
Features of Multi Blade Slicing Machine(Explanation of Each Part)
Vertically Moving Arm System
Based on our accumulated experiences, we have developed this advanced machine by adopting the mechanism of balance scales. Our machine automatically controls circular compensation with a microcomputer, resolving the disadvantage of the leverage system, and lightening the loads on a workpiece and the blades.
*Model : MB-3090A/MB-4090A
Downsized Machine
This machine has the same performance as those of conventional middle-size machines, but with a downsized height and depth compareing to the dimension of conventional machines.
Therefore, it is easy to ensure a place to install this machine.
(The picture shows MB-3090A.)
IC Board for Circular Compensation
Our Original ACA Circuit
The hoisting stage is corrected to the center of the blades' stroke and is showed in a digital display.
*Model : MB-3090A/MB-4090A
Strong Frame
We adopt a newly designed double-top frame to maintain high speed rotation and high accuracy.
*Model : MB-4090A
Operation Panel
For convenient arrangement of the switches and for users' safety, we attach a panel on the stroke adjustment plate cover.
(The picture shows MB-4090A)
Cutting Depth Indicator
This indicator shows cutting depth by 0.1mm. You can confirm it when you adjust the stroke of the blades.
With the digital switch, you can easily adjust a setting depth for automatic stop.
Abrasive Grain Outlet Lifting System
The abrasive grain outlet automatically ascend to keep a certain distance to a workpiece (2~8mm/1 step) to reduce scattered abrasive.
Vibration Level Indicator
This indicator changes its color from green, yellow to red depending on the degree of the wear of the blades to let you know the timing of stroke adjustment.
Abrasive Grain Tank
Sliding Tank
Cleaning of the tank and refilling of abrasive can be easily made.
A large filter prevents its clogging.
*Model : MB-1852/MB-2563
* MB-3090A and 4090A are for outdoor uses.
Workpiece Weight Balancing System
This power-operated variable weight is convenient for balancing with the weight of a workpiece.
Weight adjustment can easily be made by adjusting the switch.
*Model : MB-4090A
Multi Blade Slicing Machine Options
Precision vise for attaching a workpiece
This vise is made of aluminum for ease of heat radiation.
- Type BL300 : 250×300mm
- Type BL200 : 120×200mm
Jig for attaching a workpiece at certain angles
A workpiece can be attached with the reference surface of the slicing table at a certain angle.
Jig for surfaces attachment
More than one workpieces in the same size can be attached in parallel with the
reference surface of the slicing table.
3-inch wafer slicing angle adjustment stage
Correcting of parallelism of the reference surface of wafers can easily made with the direction of the blade.
Automatic angle fixing stage
An angle from the reference surface of a workpiece can be freely set on a second time scale to accurately cut it.
